Sequential – Prophet-10 Desktop Module- SEQ-1110 Genuine

Legendary 10-Voice Analog Synth Module – Prophet-10 Module Specifications:

Oscillators:

-Two authentic CEM 3340 voltage-controlled oscillators per voice

-Simultaneously selectable wave shapes.Oscillator A:Sawtooth, pulse.Oscillator B:Sawtooth, triangle, pulse

-Pulse width per oscillator

-Hard Sync:Oscillator A syncs to Oscillator B

-Low frequency mode (Oscillator B)

-Keyboard tracking on / off (Oscillator B)

Mixer:

-Oscillator A amount

-Oscillator B amount

-White noise amount

Low-Pass Filter:

-Four-pole, resonant, low-pass filter per voice

-Switchable between authentic versions of the Prophet-5 Rev1/2 filter and Prophet-5 Rev3 filter

-Rev1/2 filter is a Dave Rossum-designed 2140, the modern counterpart of the original 2040 filter found in the Prophet-5 Rev1 and Rev2

-Rev3 filter is a Doug Curtis-designed CEM 3320

-Filter can be driven into self-oscillation with the Resonance control

-Keyboard Tracking:Off, half, full

Filter Envelope:

-Four-stage (ADSR) envelope generator

-Velocity modulation of envelope amount

Amplifier Envelope:

-Four-stage (ADSR) envelope generator

-Velocity modulation of envelope amount

Low-Frequency Oscillator:

-Three wave shapes:Sawtooth, triangle, square.All wave shapes can be engaged simultaneously

-Both initial amount and mod wheel control

-Mod Destinations:Oscillator A frequency, Oscillator B frequency, Oscillator A and B pulse width, filter cutoff

Poly Mod:

-Sources:Filter envelope and Oscillator B

-Destinations:Oscillator A frequency, Oscillator A pulse width, filter cutoff

Vintage Knob:

-Recreates the characteristics of various Prophet-5 models by varying the behavior of oscillators, envelopes, amplifiers, and other parameters.Go from a very stable “4” — as in Prophet-5 Rev4 (the new version) — all the way to “1,” as in Prophet-5 Rev1, the rarest and most temperamental of all Prophet-5s

Aftertouch:

-Channel (mono) aftertouch

-Destinations:Filter cutoff frequency, LFO amount

Bi-Timbral Operation:

-Layer Mode:Two different 5-voice programs stacked together simultaneously

-Split Mode:Two independent, user-assignable performance zones, with a different 5-voice program assigned to each

Performance Controls:

-Polyphonic glide (portamento)

-Unison (monophonic) mode with configurable voice count, from one to all five voices and key modes

-Preset Switch:When off, the front panel is live; what you see is what you hear

Patch Memory:

-200 user and 200 factory programs in 5 banks of 40 programs each

-Direct program access, including Prophet 5-style single-button access to the current set of 8 programs

In / Out:

-Mono output (1 x 1/4” phone jack)

-Headphone output (stereo, 1/4” phone jack)

-MIDI in, out, and thru ports

-USB for bidirectional MIDI communication

-Control voltage in / out (1 x 1/4” phone jack) 0- +5 V input / output signal.Configured for 1-volt-per-octave operation

-Gate in / out (1 x 1/4” phone jack).Accepts a 1.5 to 15-Volt on / off signal to gate the envelopes of a single voice on the Prophet-5.Outputs a 15-Volt on / off used to gate the envelopes of an external synth

-Low-pass filter cutoff expression pedal input

-Volume expression pedal input

-Sustain footswitch input

Power:

-IEC AC power inlet for internal power supply

-Operates worldwide on voltages between 100 and 240 Volts at 50 to 60 Hz; Prophet-5: 20 Watts maximum power consumption.

Physical Specs:

-20.75″ L x 7.4″ W x 3″ H (52.70 cm x 18.8 cm x 7.62 cm)

-Roadworthy all-steel case with premium black walnut heartwood trim
